    P10 DIP 1R1G1B Large Outdoor LED Displays 10000 Nits With CE RoHS Certificate

    Ask Lasest Price
    Brand Name : NIYAKR
    Model Number : P10 DIP 1R1G1B
    Certification : CE,ROHS,EMC,UL,ISO
    Price : USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20000 Square Meters Per Month
    Delivery Time : 12-18 Working Days
    • Product Details
    • Company Profile

    P10 DIP 1R1G1B Large Outdoor LED Displays 10000 Nits With CE RoHS Certificate

    P10 DIP 1R1G1B Large Outdoor LED Displays 10000 Nits With CE RoHS Certificate


    Feature


    1. CE&RoHS certificate

    2. 36 months warranty and Life long free tech-support

    3. Excellent contrast ratio, high resolution/high definition

    4. Perect uniformity and no mosaic

    5. Waterproof IP65

    6. Light weight and easy to install


    Specification


    Pixel Pitch10mm
    Pixel Conformation1R1G1B
    Pixel Density10000 pixels/ real
    Module Dimension160×160mm
    Module Resolution16×16 dots
    Cabinet Dimension960×960×180mm
    Cabinet Resolution96×96 pixels
    Slot between cabinet≤0.3mm
    Weight of the LED display screen55kg/m2
    Screen luminance>8500 CD/m2
    Contrast≥ 750:1
    Colors16777216
    Brightness uniformityWhole Screen Luminance Discrepancy<10%
    Grey scale(typical)

    Red, Green, Blue are adjustable,

    256 levels respectively

    Optimal viewing AngleH<1200,V<550
    Optimal viewing distance10m-150m,vivid contents under sunlight
    Drive modeConstant Current, 1/4 Scan
    Refresh frequency60 HZ/s

    LED lamp life-span

    (Theoretical value under ideal state)

    100000 hours
    Mean time between failures10000 hours
    LED Display Screen life-span≥ 10 years
    Scotoma ratio<0.01%, discrete distribution
    Max. power consumption650 W/m2
    Ave. power consumption260 W/m2
    Power supply requirement220VAC/50HZ±10%
    Operating ambient temperature-20+80
    Operating ambient humidity10%95%RH
    Transmission speedHigh Speed, 40Mbit/s
    Grade of waterproofingFront: IP65, Back: IP54

    Application:


    Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc.
