    Waterproof P10 Outdoor Full Color LED Display Screen 960x960 Cabinet

    Ask Lasest Price
    Brand Name : NIYAKR
    Model Number : P10
    Certification : CE,ROHS,EMC,UL,ISO
    Price : USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20000 Square Meters Per Month
    Delivery Time : 12-18 Working Days
    • Product Details
    • Company Profile

    Waterproof P10 Outdoor Full Color LED Display Screen 960x960 Cabinet

    Waterproof P10 Outdoor Full Color LED Display Screen 960x960 Cabinet


    Product Description :


    High brightness P10 Panel Outdoor P10 SMD 3535 LED Rental Screen:


    1) High cost performance.


    2) Good Consistency and High resolution.


    3) High brightness and refresh rate .


    4) Good after-sale services.


    5) In the premise of guaranteeing quality,our company sales at low profit and warranty for 3 years.


    Advanced Control System


    a. Calibration: Pixel-by-pixel brightness and color calibration technique to keep uniform brightness and natural colors of LED display.


    b. Monitoring: Proprietary control system can monitor the temperature, brightness, status information of LED display in real time.


    c. Remote network control: Controlling and changing all display information, controlling the displays of several cities in one place to change the contents at any time.


    d. Adjustable brightness: Adjusting screen brightness automatically according to environmental lighting based on sensitive control system, adjusting it manually or by programmable menu.


    e. Large screen control: Controlling super large size display stably without any black screen, frame vibration or reducing.


    f. High refresh rate, high gray scale and high contrast ratio: More realistic pictures optimize commercial advertisement value.


    Specification

    ItemParameter
    PixelPhysical pixel pitch: 10 mm
    Pixel configuration: 1R1PG1PBWavePacking
    R620-625nmSMD-3535
    G520+/_1.25nmSMD-3535
    B470+/_1.25nmSMD-3535
    ModuleModule size: 320 x 160 mmModule resolution: 32 x 16 pixel
    CabinetCabinet size:960x960x150 mmCabinet resolution: 96 x 96pixels
    Cabinet density: 9216 pixelsModule quantity: 18 pcs
    Material: IronWeight: 50Kg
    Average power consumption: 300WMax power consumption: 720W

    Electricity

    parameter

    Brightness: ≥ 6500 nits
    Brightness adjusted: 100 grade by software, or by Auto-optic induced
    Color processing: 16bit
    Display color: 280 trillion
    Color temperature(k): 5000 — 9500 (choice by user)
    Physical density: 10000 pixels/sqm
    Whole display flatness: ≤ 1mm juncture
    Best view distance: ≥ 7m
    Best view angle: Horizontal ±80°, Vertical ±80°

    Storage temperature: -35℃ ~ +85℃

    Working temperature: -20℃ ~ +50℃

    Driving method: Constant driving current Scan: 1/4
    Refresh frequency: ≥ 1200Hz
    Frame rate: ≥ 60Hz
    Humidity(RH): ≤ 90~95%
    Protection grade: IP65
    Power supply: AC 110 / 220V, 50/60Hz
    Average power consumption: 350W/sqm
    Max power consumption: 800W/sqm
    MTBF: 10, 000 hours
    Screen lifetime: 100, 000 hours

    Control

    system

    Signal interface: DVI
    Communication distance: Internet cable: ≤120m Fiber cable: 1000m
    Signal transfer mode: Pixels to pixels display synchronized
