    Full Color Outdoor Advertising LED Display 8mm Pixel Pitch Easy Maintenance

    Ask Lasest Price
    Brand Name : NIYAKR
    Model Number : P8
    Certification : CE,ROHS,EMC,UL,ISO
    Price : USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20000 Square Meters Per Month
    Delivery Time : 12-18 Working Days
    • Product Details
    • Company Profile

    Full Color Outdoor Advertising LED Display 8mm Pixel Pitch Easy Maintenance

    Full Color Outdoor Advertising LED Display 8mm Pixel Pitch Easy Maintenance


    Features:

    • High brightness /refresh rate/color contrast ratio.


    • Energy saving IC and special design of circuit diagram, power consumption to be decreased by 35-50%.


    • Flat screen, no gap. Panels were made by high-precision molding plastic injection, no slit on the screen.


    • Professional radiant calibration system to make sure the color and brightness uniformity.


    • Perfect solution for heat ventilation, good water proof and stable performance.


    • First-class LED chip: Supplied by Silan, Cree, Epistar or other high strictly selected LED chip to

    ensure the long life time and high brightness of our LED screen system.


    Specification:


    ItemTechnical Specification
    PixelPixel pitch: 8mm
    Pixel configuration: 1R1G1B
    Brightness: Red: 600mcd Green: 2300mcd Blue: 500mcd
    Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm
    ModuleModule size: 256mmx128mm
    Module resolution:32x16 pixels
    CabinetCabinet resolution: 12288 pixels
    Cabinet material: Steel
    Gross weight: 55kg
    Module quantity: 32pcs= 8(w) x 4(h)
    Cabinet size: 1024mm×768mm×150mm
    Power consumption : Max.:1200W/m² Average: 500W/m²
    Screen parameterDrive method: 1/4 scanning
    Brightness: 8000cd/m²
    IC driver: MBI 5024
    Density: 15625pixel/m²
    Whole display flatness: ≤ 1mm juncture
    Best view distance: ≥ 16m
    Viewing angle: Horizontal: 120° Vertical: 60°
    Humidity(RH): ≤ 90~95%
    Working temperature: from -20°C~ +50°C
    Working voltage: AC220V/110V±20%
    Refresh frequency: ≥ 300Hz(Linsn)
    Frame rate: ≥ 540Hz
    Protection grade: IP67
    MTBF: More than 10000hrs
    Life time: 100,000 hrs
    Control systemControl system: Linsn
    Signal interface: DVI
    Communication distance: The shielded twisted-pair cable transmission distance for 100 meters, the biggest up to 140 m. Multimode fiber of up to 500 meters, the single-mode optical fiber to 20 kilometers
    Systems operating platforms :XP,WINDOWS(WIN95,WIN98,WIN2000)
    Input Signal:RF,S-VIDEO,RGBTV,YUT,YC,COMPOSITION
    Image adjustment:contrast, tonal, the color saturation, gray calibration coefficient, color range, image variable times, etc
    Life span:100,000 hours
    Out-of Control rate:0.0001
    Control system:Synchronized
    Operating Environment Temperature :-20°C—65°C Optional
