    SMD P8 Full Color LED Display Screen External LED Display 1R1G1B 64X64mm Cabinet

    Ask Lasest Price
    Brand Name : NIYAKR
    Model Number : P8
    Certification : CE,ROHS,EMC,UL,ISO
    Price : USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20000 Square Meters Per Month
    Delivery Time : 12-18 Working Days
    • Product Details
    • Company Profile

    SMD P8 Full Color LED Display Screen External LED Display 1R1G1B 64X64mm Cabinet

    SMD P8 Full Color LED Display Screen External LED Display 1R1G1B 64X64mm Cabinet


    FIXED TYPE OUTDOOR SMD P8 LED DISPLAY TECHNICAL PARAMETERS
    Unit ModuleItemNIYAKR-PH8-4S
    Module size256mm*128mm
    Pixel pitch8mm
    Pixels Density1RGB 3in1
    Pixel configuration1R1G1B
    Package modeSMD3535
    Pixel resolution32dots(W)*16 dots(H)
    Drive typeConstant drive IC
    Scan mode1/4can
    Port typeHUB75-A
    Brightness of white balance≥6500cd/m2
    LED Display CabinetDimension512mm*512mm
    Monomer Module Number8
    Pixel per cabinet64mm*64mm
    Best viewing distance10M~50M
    Best viewing angle160°(W) 120°(H)
    Temperaturestorage:-35℃~+85℃
    working:-20℃~+50℃
    Relative humidity10%-95%
    Thickness85mm
    PowerWorking voltageAC110V/AC220V±10%
    Average Power consumption120W/m2
    Max.Power consumption≤390W/m2
    Current≤20mA(single LED)
    Control SystemCPUPentium4 or above
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization
    Main Technical ParameterDriving deviceConstant drive IC
    Refresh frequency≥1200HZ
    Grey scale/colors4096gray level/16.7M colors
    MTBF≥10000hours
    Power switchAutomatic switch
    Display Mode≥800*600/1024*768
