    P1.56 3D Advertising Full Hd LED Screen With 3840HZ Nationstar MBI5153

    Ask Lasest Price
    Brand Name : NIYAKR
    Model Number : P1.56
    Certification : CE,ROHS,EMC,UL,ISO
    Price : USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 8000 Square Meters Per Month
    Delivery Time : 10-15 Working Days
    • Product Details
    • Company Profile

    P1.56 3D Advertising Full Hd LED Screen With 3840HZ Nationstar MBI5153

    P1.56 3D Advertising Full Hd LED Screen With 3840HZ Nationstar MBI5153


    Feature:

    1. High refresh rate and gray level ensures the picture quality remains seamless.
    2. Perfect cabinet size,16:9,can display the image to the best.
    3. Low consumption, stable performance, highly durable,High definition image.
    4. Integrated cabinet design,flatness<0.2mm.
    5. Light weight cabinet, 7.8KG/cabinet, only 1 people can make the installation and maintance.
    6. flightcase package, easy to take the LED screen to different places according to your business needs.
    7. Super thin, humanized designith handles and fast locks, easy to install.


    Specification:


    P1.56 Indoor HD LED Display
    S/NItemTechnical Parameters
    LED Parameters
    1Item NameLED TypeBrightnessWave LengthH/V Visual Angle
    2Red LEDSMD1010100-120mcd620-625nm140º/60º
    3Green LEDSMD1010320-400mcd520-525nm140º/60º
    4Blue LEDSMD101070-90mcd470-475nm140º/60º
    Module Specifications
    1Pixel Pitch1.56mm
    2Pixel ConfigurationSMD3in1
    3Module Resolution128x192 pixels
    4Module Pixles24,576 pixels
    5Module Size200x300mm
    Cabinet Specifications
    1Cabinet Size(W X H X D)400x300mm
    2Cabinet Resolution(dot)256 x 192 pixels
    3Module Quanity (pcs)2pcs
    4Cabinet Pixels49,152 pixels
    5Pixel Density409600 pixels/m2
    6Cabinet MaterialsDie Casting Aluminum
    Whole Screen Specifications
    1Screen Brightness≥1000cd/m2
    2Driving Method1/32 scan
    3Mini Viewing Distance2m
    4Max. Power Consumption800W/m2
    5Average Power Consumption400W/m2
    6Gray Level8bits input, 4096 levels(212)
    7Display Color16M
    8Frame Frequency≥60Hz
    9Refresh Frequency≥3840Hz
    10Uninterrupted Working Hours≥72 hours
    11Screen Life-span≥100,000 hours
    12MTBF≥5,000 hours
    13Discrete Blind Spot Rate<1/10000
    14Continuous Blind Spot RateNone
    15Blind Spot Rate<1/10000
    16Screen Plainness<±1mm
    17Power Supply ModeAC220±10% 50Hz/AC110±10% 60Hz
    18Environment Temperature & HumidityTemperature:-20 Celsius~+60 Celsius
    Humidity:10%~90% RH
    19Control ModeSynchronous display with control PC by DVI
    20Control SystemDVI video card + full color control card + fiber system( optional)
    21Display ContentVideo, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
    22InterfaceStandard Ethernet
    23Transmission DistanceMulti mode fiber <500m, single mode fiber <30km,internet cable <100m
